1592025700 IPROFAMILY stp GB 2012.08.08.doc iPro Series 41/72
Digital outputs with SSR relays (IPX125D)
4 NO relays, 2 common
Digital relay outputs (IPX125D)
6 NO relays, 2 common
Green power LEDs (PWR ON) and red alarm signal LED (ALARM)
See relative paragraph
4.6.2 Description of the inputs and outputs
Input
No.
Type of Input Description
1 Supply Reference “-“/GND power (24Vac or 24Vdc)
2 Pb1
Configurable analogue input 1 (NTC, PTC, PT1000, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 -
5V, DI)
3 Pb2
Configurable analogue input 2 (NTC, PTC, PT1000, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 -
5V, DI)
4 Pb3
Configurable analogue input 3 (NTC, PTC, PT1000, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 -
5V, DI)
5 Pb4
Configurable analogue input 4 (NTC, PTC, PT1000, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 -
5V, DI)
6 Pb5
Configurable analogue input 5 (NTC, PTC, PT1000, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 -
5V, DI)
7 PbC Common analogue inputs (NTC, PTC, PT1000, DI)
8 GND(-)
Additional power reference 5Vdc and 12Vdc and analogue inputs (0 - 20mA, 4 - 20mA, 0 -
10V, 0 - 1V, 0 - 5V)
9 Supply Reference “+“ power supply (24Vac or 24Vdc)
10 Pb6
Configurable analogue input 6 (NTC, PTC, PT1000, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 -
5V, DI)
11 Pb7
Configurable analogue input 7 (NTC, PTC, PT1000, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 -
5V, DI)
12 Pb8
Configurable analogue input 8 (NTC, PTC, PT1000, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 -
5V, DI)
13 Pb9
Configurable analogue input 9 (NTC, PTC, PT1000, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 -
5V, DI)
14 Pb10
Configurable analogue input 10 (NTC, PTC, PT1000, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 -
5V, DI)
15 +5V Additional power +5Vdc
16 +12V Additional power +12Vdc
21 Out1 Opto-insulated analogue output 1 0 - 10V
22 Out2 Opto-insulated analogue output 2 0 - 10V
23 Out3 Opto-insulated analogue output 3 0 - 10V
24 Out4 Opto-insulated analogue output 4 0 - 10V
25 GND(-) Common opto-insulated analogue output
26 Out5 Analogue output 5 0 - 10V, 4 - 20mA, Opto-insulated relay
27 Out6 Analogue output 6 0 - 10V, 4 - 20mA, Opto-insulated relay
28 Supply Power for opto-insulated analogue outputs at 24Vac or 24Vdc(-)
29 Supply Power for opto-insulated analogue outputs at 24Vac or 24Vdc(+)
30 GND(-) Common opto-insulated analogue output
40 DI1 Opto-insulated digital input 1
41 DI2 Opto-insulated digital input 2
42 DI3 Opto-insulated digital input 3
43 DI4 Opto-insulated digital input 4
44 DI5 Opto-insulated digital input 5
45 DI6 Opto-insulated digital input 6
46 DI7 Opto-insulated digital input 7
47 DI8 Opto-insulated digital input 8
