1592025700 IPROFAMILY stp GB 2012.08.08.doc iPro Series 13/72
4.1.2 Description of the inputs and outputs
Input
No.
Type of Input Description
1 Supply Reference “-“/GND power (24Vac or 24Vdc)
2 Pb1 Configurable analogue input 1 (NTC, PTC, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 - 5V, DI)
3 Pb2 Configurable analogue input 2 (NTC, PTC, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 - 5V, DI)
4 Pb3 Configurable analogue input 3 (NTC, PTC, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 - 5V, DI)
5 Pb4 Configurable analogue input 4 (NTC, PTC, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 - 5V, DI)
6 Pb5 Configurable analogue input 5 (NTC, PTC, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 - 5V, DI)
7 PbC Common analogue inputs (NTC, PTC, DI)
8 GND (-)
Additional power reference 5Vdc and 12Vdc and analogue inputs (0 - 20mA, 4 - 20mA, 0 - 10V,
0 - 1V, 0 - 5V)
9 Supply Reference “+“ power supply (24Vac or 24Vdc)
10 Pb6 Configurable analogue input 6 (NTC, PTC, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 - 5V, DI)
11 Pb7 Configurable analogue input 7 (NTC, PTC, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 - 5V, DI)
12 Pb8 Configurable analogue input 8 (NTC, PTC, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 - 5V, DI)
13 Pb9 Configurable analogue input 9 (NTC, PTC, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 - 5V, DI)
14 Pb10 Configurable analogue input 10 (NTC, PTC, 0 - 20mA, 4 - 20mA, 0 - 10V, 0 - 1V, 0 - 5V, DI)
15 +5V Additional power +5Vdc
16 +12V Additional power +12Vdc
21 Out1 Analogue output 1 0 - 10V
22 Out2 Analogue output 2 0 - 10V
23 Out3 Analogue output 3 0 - 10V
24 Out4 Analogue output 4 0 - 10V
25 GND(-) Additional power reference 12Vdc and analogue outputs
26 Out5 Analogue output 5 0 - 10V, 4 - 20mA, Relay (if TF1 is not used)
27 Out6 Analogue output 6 0 - 10V, 4 - 20mA, Relay (if TF2 is not used)
28 TF1 Analogue output TF1 PWM (if Out5 is not used)
29 TF2 Analogue output TF2 PWM (if Out6 is not used)
30 +12V Additional power +12Vdc
40 DI1 Opto-insulated digital input 1 (potential free contact)
41 DI2 Opto-insulated digital input 2 (potential free contact)
42 DI3 Opto-insulated digital input 3 (potential free contact)
43 DI4 Opto-insulated digital input 4 (potential free contact)
44 DI5 Opto-insulated digital input 5 (potential free contact)
45 DI6 Opto-insulated digital input 6 (potential free contact)
46 DI7 Opto-insulated digital input 7 (potential free contact)
47 DI8 Opto-insulated digital input 8 (potential free contact)
48 DI9 Opto-insulated digital input 9 (potential free contact)
49 DI10 Opto-insulated digital input 10 (potential free contact)
50 DIC Common opto-insulated digital inputs 1 to 20
51 DI11 Opto-insulated digital input 11 (potential free contact)
52 DI12 Opto-insulated digital input 12 (potential free contact)
53 DI13 Opto-insulated digital input 13 (potential free contact)
54 DI14 Opto-insulated digital input 14 (potential free contact)
55 DI15 Opto-insulated digital input 15 (potential free contact)
56 DI16 Opto-insulated digital input 16 (potential free contact)
57 DI17 Opto-insulated digital input 17 (potential free contact)
