1592025700 IPROFAMILY stp GB 2012.08.08.doc iPro Series 19/72
4.1.3.7 Mechanical specifications
10 DIN module
4.1.3.8 Electrical specifications
Power Supply: 24Vac +10/-15%, 50/60Hz
20 - 36Vdc
Consumption: 20VA (Vac), 15W (Vdc)
Connectors: Molex connectors with low voltage wiring
SELECOM/CIVILUX connectors for digital outputs (250Vac, 6A max)
Microprocessor: AT91RM9200 32-bit 200Mhz
Permanent FLASH memory: 128MB, in 8-bit
RAM: 32MB or 64MB, in 16-bit
Internal clock: standard
4.1.3.9 Plastic container
Mount: On a DIN rail (EN 50022, DIN 43880)
Fastened with screws via the removable plastic flaps.
Material: PC-ABS Thermoplastic
Self-extinguishing: V0 (UL94)
Comparative Tracking Index (CTI): 300V
Colour: Black
4.1.3.10 Product certifications
Control to classify with the definitions 2.5.1 e 2.5.2 mentioned in the section 2.5 of the general
requirements EN60730-1 (2.5.1 = integrated control, 2.5.2 = incorporated control).
Electrical safety:
EN60730-1
Electromagnetic compatibility:
EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8,
EN61000-4-11
