1592025700 IPROFAMILY stp GB 2012.08.08.doc iPro Series 27/72
4.3 IPRO 4 DIN (IPG100D – IPG200D – IPC100E RANGES)
4.3.1 Description of the connections
Connector Description
Connector for 24Vac/dc power supply
Analogue inputs (Pb1 - Pb6, PbC)
Additional power (+5Vdc, +12Vdc, GND)
Analogue outputs (Out1 - Out4, GND)
