1592025700 IPROFAMILY stp GB 2012.08.08.doc iPro Series 49/72
116 RL17 SSR relay 17 normally open contact
117 RL18 SSR relay 18 normally open contact
118 RL19 SSR relay 19 normally open contact
119 P Common SSR relays 16, 17, 18 and 19
120 RL24 Relay 24 normally open contact
121 P Common relays 24 and 25 (MAX 6A)
122 RL25 Relay 25 normally open contact
4.7.3 Technical specifications
4.7.3.1 Analogue inputs
Analogue conversion type: 10-bit A/D converter
Number of inputs: 10
Type of analogue input:
(configurable via software parameter)
NTC Dixell (-50T110°C; 10KΩ±1% at 25°C)
PTC Dixell(-55T115°C; 990Ω±1% at 25°C)
PT1000 Dixell (-100T150°C; 1KΩ at 0°C)
Digital input (potential free contact)
Voltage: 0 - V, 0 - 5V, 0 - 10V (input resistance 15KΩ )
Current: 0 - 20mA, 4 - 20mA (input resistance 100Ω)
Digital input status variation detection time: 100ms (in any case it depends on the cycle time set by the user in the
given application)
Accuracy: NTC, PTC, PT1000: ±1°C
0-1V: ±20mV
0-5V: ±100mV
0-10V:±200mV
2-20mA, 4-20mA: ±0.30mA
Additional power: +12V: 200mA max
+5v: 100mA
Notes: Any inputs that are powered with a voltage that differs from that supplied
by the device (+12V or +5V) must be powered separately with another
transformer (do not use the same secondary of the controller's power) in
order to prevent the inputs from malfunctioning or being damaged.
4.7.3.2 Digital inputs
Type:
(configurable via software parameter)
Opto-insulated potential free or live contact (24Vac/dc)
External power 24Vac/dc ±20%
Number of inputs: 20
Digital input status variation detection time: 100ms (in any case it depends on the cycle time set by the user in the
given application)
Notes:
If the digital inputs are used with voltage, use another transformer (do not
use the same secondary of the controller's power) in order to prevent the
inputs from malfunctioning or being damaged.
4.7.3.3 Analogue outputs
Type: Opto-insulated with separate 24Vac/dc power supply
Number of outputs: 6
Type of analogue output:
(configurable via software parameter)
4 fixed outputs 0-10Vdc (Out1 - Out4)
2 configurable outputs 0-10Vdc, 4-20mA (Out5 and Out6)
Maximum load: 40mA (Out1 - Out4)
20mA (Out5 and Out6) max with configured outputs 0-10Vdc
400Ω max with configured outputs 4-20mA
22Ω per live analogue output
Accuracy: Out1 - Out4: ±2% full scale
Out5 – Out6: ±2% full scale
Resolution: 8bit
Notes: The electrical devices controlled by these analogue outputs must be
powered separately with another transformer (do not use the same
secondary of the controller's power) in order to prevent the outputs from
malfunctioning or being damaged.
