1592025700 IPROFAMILY stp GB 2012.08.08.doc iPro Series 48/72
48 DI9 Opto-insulated digital input 9
49 DI10 Opto-insulated digital input 10
50 GND(-) Reference “-“ for opto-insulated digital inputs 1 to 20 (if inputs 24Vac or 24Vdc)
51 DI11 Opto-insulated digital input 11
52 DI12 Opto-insulated digital input 12
53 DI13 Opto-insulated digital input 13
54 DI14 Opto-insulated digital input 14
55 DI15 Opto-insulated digital input 15
56 DI16 Opto-insulated digital input 16
57 DI17 Opto-insulated digital input 17
58 DI18 Opto-insulated digital input 18
59 DI19 Opto-insulated digital input 19
60 DI20 Opto-insulated digital input 20
61 IDC Common opto-insulated digital inputs 1 to 20 (if potential free inputs)
70 RL1 Relay 1 normally open contact
71 P Common relays 1, 2 and 3 (MAX 6A)
72 RL2 Relay 2 normally open contact
73 RL3 Relay 3 normally open contact
74 N Potential free contact (MAX 6A)
75 N Potential free contact (MAX 6A)
76 RL4 Relay 4 normally open contact
77 RL5 Relay 5 normally closed contact
78 RL6 Relay 6 normally closed contact
79 RL7 Relay 7 normally closed contact
80 P Common relays 4, 5, 6, 7 and 8 (MAX 6A)
81 RL8 Relay 8 normally closed contact
82 N Potential free contact (MAX 6A)
83 N Potential free contact (MAX 6A)
84 RL9 Relay 9 normally closed contact
85 RL10 Relay 10 normally closed contact
86 P Common relays 9 and 10 (MAX 6A)
87 RL11 Relay 11 normally closed contact
88 RL12 Relay 12 normally closed contact
89 RL13 Relay 13 normally closed contact
90 P Common relays 11, 12, 13, 14 and 15 (MAX 6A)
91 RL14 Relay 14 normally closed contact
92 RL15 Relay 15 normally closed contact
93 C Potential free contact (MAX 6A)
100 CAN Bus CAN Bus connection (+), not open
101 CAN Bus CAN Bus connection (-), not open
102 CAN Bus CAN Bus connection (insulated gnd), not open
103 LAN LAN Connection (+)
104 LAN LAN Connection (-)
109 C Potential free contact (MAX 6A)
110 P Common relays 20, 21, 22 and 23 (MAX 6A)
111 RL20 Relay 20 normally open contact
112 RL21 Relay 21 normally open contact
113 RL22 Relay 22 normally open contact
114 RL23 Relay 23 normally open contact
115 RL16 SSR relay 16 normally open contact
To Next Page
