dixell iPro SERIES User Manual

1592025700 IPROFAMILY stp GB 2012.08.08.doc iPro Series 42/72
48 DI9 Opto-insulated digital input 9
49 DI10 Opto-insulated digital input 10
50 GND(-) Reference “-“ for opto-insulated digital inputs 1 to 20 (if inputs 24Vac or 24Vdc)
51 DI11 Opto-insulated digital input 11
52 DI12 Opto-insulated digital input 12
53 DI13 Opto-insulated digital input 13
54 DI14 Opto-insulated digital input 14
55 DI15 Opto-insulated digital input 15
56 DI16 Opto-insulated digital input 16
57 DI17 Opto-insulated digital input 17
58 DI18 Opto-insulated digital input 18
59 DI19 Opto-insulated digital input 19
60 DI20 Opto-insulated digital input 20
61 IDC Common opto-insulated digital inputs 1 to 20 (if potential free inputs)
70 RL1 Relay 1 normally open contact
71 RL2 Relay 2 normally open contact
72 RL3 Relay 3 normally open contact
73 C Common relays 1, 2, 3 and 4 (MAX 6A)
74 RL4 Relay 4 normally open contact
75 RL3 Relay 3 normally closed contact
76 C Common relays 5, 8 and 9 (MAX 6A)
77 RL5 Relay 5 normally open contact
78 RL6 Relay 6 normally open contact
79 RL7 Relay 7 normally open contact
80 RL8 Relay 8 normally open contact
81 RL9 Relay 9 normally open contact
82 RL10 Relay 10 normally open contact
83 C Common relays 6, 7 and 10 (MAX 6A)
84 RL11 Relay 11 normally open contact
85 RL12 Relay 12 normally open contact
86 RL13 Relay 13 normally open contact
87 C Common relays 12, 13 and 15 (MAX 6A)
88 C Common relays 12, 13 and 15 (MAX 6A)
89 RL11 Relay 11 normally closed contact
90 C Common relays 11 and 14 (MAX 6A)
91 RL14 Relay 14 normally open contact
92 RL14 Relay 14 normally closed contact
93 RL15 Relay 15 normally open contact
100 CAN Bus CAN Bus connection (+), not open
101 CAN Bus CAN Bus connection (-), not open
102 CAN Bus CAN Bus connection (insulated gnd), not open
103 LAN LAN Connection (+)
104 LAN LAN Connection (-)
120 RL16 SSR relay 16 normally open contact
121 C Common relays 16, 17, 18 and 19
122 RL18 SSR relay 18 normally open contact
123 RL17 SSR relay 17 normally open contact
124 C Common relays 16, 17, 18 and 19
125 RL19 SSR relay 19 normally open contact
126 RL20 Relay 20 normally open contact
