1592025700 IPROFAMILY stp GB 2012.08.08.doc iPro Series 23/72
59 DI19 Opto-insulated digital input 19
60 DI20 Opto-insulated digital input 20
61 IDC Common opto-insulated digital inputs 1 to 20 (if potential free inputs)
70 RL1 Relay 1 normally open contact
71 C Common relays 1, 2 and 3 (MAX 6A)
72 RL2 Relay 2 normally open contact
73 RL3 Relay 3 normally open contact
74 C Potential free contact (MAX 6A)
75 C Potential free contact (MAX 6A)
76 RL4 Relay 4 normally open contact
77 RL5 Relay 5 normally open contact
78 RL6 Relay 6 normally open contact
79 RL7 Relay 7 normally open contact
80 C Common relays 4, 5, 6, 7 and 8 (MAX 6A)
81 RL8 Relay 8 normally open contact
82 C Potential free contact (MAX 6A)
83 C Potential free contact (MAX 6A)
84 RL9 Relay 9 normally open contact
85 RL10 Relay 10 normally open contact
86 C Common relays 9 and 10 (MAX 6A)
87 RL11 Relay 11 normally open contact
88 RL12 Relay 12 normally open contact
89 RL13 Relay 13 normally open contact
90 C Common relays 11, 12, 13, 14 and 15 (MAX 6A)
91 RL14 Relay 14 normally open contact
92 RL15 Relay 15 normally open contact
93 C Potential free contact (MAX 6A)
94 RS485 Master RS485 Master connection (-)
95 RS485 Master RS485 Master connection (+)
96 RS485 Master RS485 Master connection (insulated gnd)
97 RS485 Slave RS485 Slave connection (-)
98 RS485 Slave RS485 Slave connection (+)
99 RS485 Slave RS485 Slave connection (insulated gnd)
100 CAN Bus CAN Bus connection (+), not open
101 CAN Bus CAN Bus connection (-), not open
102 CAN Bus CAN Bus connection (insulated gnd), not open
103 Remote Display Connection for VISOGRAPH remote terminal (Vnr)
104 Remote Display Connection for VISOGRAPH remote terminal (+)
105 Remote Display Connection for VISOGRAPH remote terminal (-)
106 Modem Reset NC relay input to reset an external modem (24Vac/dc)
107 Modem Reset NC relay output to reset an external modem (24Vac/dc)
