Page 84
Short Gate Detail
INDEX
NUMBER
PART NUMBER PART DESCRIPTION
ASSY. W449 Short Gate Assembly
1 W430 Frame, Bottle Release Mechanism
2 W435 Knuckle, Front, Release Mechanism
3 W458-2 Pin, Knuckle Hinge, Release Mechanism
4 W458-1 Pin, Front Knuckle, Release Mechanism
5 W462 Knuckle, Rear, Release Mechanism
6 W458-3 Pin, Solenoid, Release Mechanism
7 W458-4 Pin, Front Shuttle, Release Mechanism
8 W431 Shuttle, Rear, Release Mechanism
9 W768 Shuttle, Rear Shuttle, 4.12 lb/in
10 W432 Shuttle, Front, Release Mechanism
Part numbers subject to change without notice.
