Page 86
Short Gate Tray Detail
INDEX
NUMBER
PART NUMBER PART DESCRIPTION
ASSY. W274 Short Gate Tray Assy.
1 W980 Solenoid, Bottle Release
2 W449 Short Gate Assembly
3 W083 Chassis, Tray, Short Gate
4 Spacer
W168-1 Spacer Kit, Short Gate, 3/16”, 9 ea. (Includes D168)
W168-2 Spacer Kit, Short Gate, 3/8”, 9 ea. (Includes D168)
W168-3 Spacer Kit, Short Gate, 9/16”, 9 ea. (Includes D168)
5 D168 Screw, Hex Head, Spacer Retainer (Bag of 10)
6 801,810,600.01 Slide, w/ArmorAll (Tray Insert), 6 Tray only Short Gate
D330-1DS Slide, w/delrin & silicon (Tray Insert), 5 Tray Short Gate
7 W789 Cotter Pin
8 W311 Tray, Wire, Formed
9 622,070,040.03 Bracket, Side, Tray
10 W834 End Cap
11 W398 Washer, Retainer
Part numbers subject to change without notice.
