DKS 1802 - Automatic Hang-Up Function; Programming the Directory Code Length; Section 3.2 Phone Number and Directory Code Programming; System to Stay On-Line or Hang-Up after Touch-Tone Number Pressed

1802-065-D-10-14
24
This programming sequence provides a method for the telephone entry system to remain on-line after a resident has pressed
the touch tone number to open the door or gate. Each relay can be set independently to either remain on line or hang up.
Factory setting = 1 (hang up after touch tone number pressed) for both relays.
3.1.13 System to Stay On-Line or Hang Up after Touch Tone Number Pressed
1. Press and enter your four-digit MASTER CODE (beep).
2. Press (beep) for relay 1, OR (beep) for relay 2.
3. Press (beep) to keep the system on-line, OR (beep) to make it hang up.
4. Repeat steps 2 and 3 to program other relay.
5. Press together to end this programming sequence (beeeeeep).
?
?
?
?
?
?
?
?
8
8
TUV
TUV
2
2
ABC
ABC
0
0
OPER
OPER
This programming sequence determines when the phone system will automatically hang itself up after a predetermined time of
inactivity. You can program the system to not hang-up (0), to hang-up after 5 sec of dial-tone (1), to hang-up after 15 sec of
silence (2) or to hang-up after either 5 sec of dial-tone or 15 sec of silence (3).
Factory setting = 1 (hang-up after 5 sec of dial-tone).
3.1.14 Automatic Hang-up Function
1. Press and enter your four-digit MASTER CODE (beep).
2. Enter the single-digit hang-up code desired (0, 1, 2 or 3), then press (beep).
3. Press together to end this programming sequence (beeeeeep).
?
?
?
?
?
?
?
?
0
0
OPER
OPER
4
4
GHI
GHI
0
0
OPER
OPER
0
0
OPER
OPER
1
1
SP
SP
0
0
OPER
OPER
1
1
SP
SP
1
1
SP
SP
This programming sequence sets the directory code length to 1 - 2 - 3 or 4 digits. If 11 or more resident names or telephone
numbers are going to be programmed into the system, the directory code must be at least two-digits. If 101 or more resident
names or telephone numbers are going to be programmed, the directory code must be at least three-digits.
Factory setting is three (3) digits.
3.2.1 Programming the Directory Code Length
1. Press and enter your four-digit MASTER CODE (beep).
2. Enter the directory code digit length (1, 2, 3 or 4), then press (beep).
3. Press (beep) to cancel this function, OR (beeeeeep) to confirm the change.
The programming sequence will automatically end itself after pressing . This CANNOT be UNDONE!
?
?
?
?
?
?
?
?
0
0
OPER
OPER
2
2
ABC
ABC
1
1
SP
SP
2
2
ABC
ABC
0
1
2
3
No hang-up.
Hang-up after 5 sec. of dial-tone (Factory setting).
Hang-up after 15 sec. of silence.
Hang-up after 5 sec. of dial-tone OR 15 sec. of silence.
Hang-up Code Function
3.2 Phone Number and Directory Code Programming
CAUTION: After programming this sequence, it is NOT recommended changing the directory code length.
Reprogramming this sequence in the future will delete ALL phone numbers and directory codes that have
been previously programmed into the system.
