DKS 1802 - System Administrator; Remote Programming (Touch-Tone Phone); Remote Relay Activation; Remote Relay Check

1802-065-D-10-14
37
This programming sequence sets up ONE time zone for the FIVE-digit entry codes to activate the system relays. This time zone
uses a range of five-digit entry codes (Boundary numbers) and can be programmed for certain days of the week. This time zone
can be turned ON and turned OFF after it is programmed (see operating instructions 4.2.4 to turn ON or OFF the programmed
entry code time zone).
Note: FLASH entry codes can NOT be used with five-digit entry codes.
3.5.4 Five-Digit Entry Codes Time Zone
1
1
SP
SP
0
0
OPER
OPER
1
1
SP
SP
0
0
OPER
OPER
1. Press and enter your four-digit MASTER CODE (beep).
2. Press (beep) to turn time zone ON, OR (beep) to turn time zone OFF.
3. Enter the four-digit BEGINNING hour and minutes, then press (beep).
DO NOT use military (24 hour) time format, simply enter the hour (2 digits) and the minutes (2 digits). For example, 8:30 is
entered as 0830. AM or PM gets set on the next step.
4. Press (beep) for AM, OR (beep) for PM.
5. Enter the four-digit ENDING hour and minutes, then press (beep).
DO NOT use military (24 hour) time format, simply enter the hour (2 digits) and the minutes (2 digits). For example, 8:30 is
entered as 0830. AM or PM gets set on the next step.
6. Press (beep) for AM, OR (beep) for PM.
7. Enter the seven-digit days of the week, then press (beeeeeep). (Sun = 1, Mon = 2, .....Sat = 7)
All seven digits MUST be entered, to skip any days of the week the time zone will NOT be active, enter # in place of a day.
Example 1: to have a time zone active on Saturday and Sunday ONLY (Sun = 1, Sat = 7), enter 1 7 # # # # #.
Example 2: to have a time zone active on Monday thru Friday ONLY (Mon = 2, Tues = 3, ......Fri = 6), enter 2 3 4 5 6 # #.
8. Enter the LOWER five-digit entry codes boundary number, then press (beep).
Entry codes LOWER than this number will NOT activate relays when the entry code time zone is ON.
9. Enter the UPPER five-digit entry codes boundary number, then press (beep).
Entry codes HIGHER than this number will NOT activate relays when the entry code time zone is ON.
10. Press together to end this programming sequence (beeeeeep).
?
?
?
?
?
?
?
?
7
7
PQRS
PQRS
3
3
DEF
DEF
1
1
SP
SP
0
0
OPER
OPER
0
0
OPER
OPER
This programming sequence sets up “Flash Entry Codes”. Flash codes are four-digit entry codes that will operate ONLY ONE
TIME on a specific day of the month - they will not operate before or AFTER the programmed day. The flash codes will be valid
for a single 24-hour period ONLY. For example, if you program a flash code on July 1st to be active on the 10th, the code will
become valid at 00:00 AM on July 10th and expire at 11:59 PM on July 10th. The code will not be valid on August 10th. You can
program up to EIGHT flash codes in the system.
Flash code numbers 1 through 4 will activate Relay 1 ONLY.
Flash code numbers 5 through 8 will activate Relay 2 ONLY.
3.5.5 “Flash Entry Codes” - Active for ONE-DAY ONLY
1. Press and enter your four-digit MASTER CODE (beep).
2. Enter a single-digit flash code number (1-8 depending on which relay is to be activated), then press (beep).
3. Enter the two-digit day of the month that the code is to be active, then press (beep).
4. Enter a desired four-digit FLASH ENTRY CODE, then press (beep).
6. Repeat steps 2 through 4 to enter additional desired FLASH ENTRY CODES.
4. Press together to end this programming sequence (beeeeeep).
?
?
?
?
?
?
?
?
5
5
JKL
JKL
1
1
SP
SP
0
0
OPER
OPER
