Digital Monitoring Products, Inc. | 734 Installation and Programming Guide 17
PROGRAM THE 734
When you program a 734, you can use a keypad connected to the 734 programming
header and set to address 1. For 12V applications, connect the keypad to the module
using a Model 330 4‑wire harness. For 24V applications, connect the keypad to the
module using a Model 330‑24 4‑wire programming harness with in‑line resistor.
Caution: Do not connect a keypad using a standard Model 330 harness if using a
24V power supply! Damage to the keypad could occur.
You can also program the 734 from an XR150/XR550 Series panel. If you choose to
program the 734 from the panel, all future programming should be performed through
the panel. The panel’s programming overrides any programming performed from a
keypad connected to the 734. While the 734 is in programming mode, it will not be able
to communicate with the panel.
