DMP Electronics 734 Installation And Programming Guide

Digital Monitoring Products, Inc. | 734 Installation and Programming Guide 7
Isolation Relay (optional)
The Form C relay can control a device that draws less than 10Amps of current. If
a device draws more than 10Amp of current, or the sum of all devices controlled
by the Form C relay exceeds 10Amps, an isolation relay must be used. Refer to
Figures5 and 6 for isolation relay wiring.
3
RED
PROG
J2
RED
J5
RED
KYPD IN
J4
KYPD OUT
J1
DATA
XMT LED
WIEGAND
READ LED
RELAY
ON
NCCNO
GRNYELRED
+ –
Piezo
Model 333
Suppressor
Normally Open
–+
Magnetic Lock
–+
Isolation Relay
To Panel
Keypad Bus
12/24 VDC
Power
Supply
NCCNO
RED
PROG
J2
RED
J5
RED
KYPD IN
J4
KYPD OUT
J1
DATA
XMT LED
WIEGAND
READ LED
RELAY
ON
NCCNO
GRNYELRED
+ –
Piezo
Model 333
Suppressor
Normally Open
–+
DC Door Strike
–+
Isolation Relay
To Panel
Keypad Bus
12/24 VDC
Power
Supply
NCCNO
Figure6: Door Strike with an Isolation
Relay
Figure5: Magnetic Lock with an Isolation
Relay

DMP Electronics 734 Specifications

General

Brand	DMP Electronics
Model	734
Category	Control Unit
Language	English
