Digital Monitoring Products, Inc. | 734 Installation and Programming Guide 27
Number of User Code Digits
The 734 module recognizes user codes from 4‑12digits long.
Press any top row select key or area to enter a user code
digit length. This number must match the user code number
length being programmed in the panel. The device will
recommend a number of user code digits based on the user
code length. Default is 5.
All bits are read and converted into a decimal number string.
The number string is left padded with 0 (zero) if needed for
long user code lengths.
Example: # decoded 1234567
10 digits 0001234567
4 digits 4567
NO OF USER CODE
DIGITS: 5
To Next Page
