Digital Monitoring Products, Inc. | 734 Installation and Programming Guide 25
Site Code Position and Length
Enter the site code start position and length in the data
string. Press select area 2 to clear the site code start position
and enter a number between 0‑255. Press CMD to save.
Default is 1.
Press select area 4 to clear the site code length and enter a
number between 1‑24. Press CMD to save. Default is 8.
User Code Position and Length
Define the user code start bit position and length. Press
select area 2 to clear the user code position and enter a
number between 0‑255. Press CMD to save. Default is 9.
Press select area 4 to clear the user code length and enter a
number between 16‑64. Press CMD to save. Default is 16.
SITE CODE
POS: 1 LEN: 8
USER CODE
POS: 9 LEN: 16
