Digital Monitoring Products, Inc. | 734 Installation and Programming Guide 9
Wire the Zone Terminals
Terminals 8 through 12 connect grounded zones1 through 3. These zones have a
grounded side and cannot be used for fire‑initiating devices. Zones 2 and 3 can
also be used for access control with zone2 providing a bypass feature and zone3
providing request to exit functionality.
Terminals 13 and 14 connect to zone4. Zone 4 provides a non‑powered Class B
ungrounded zone suitable for connection to fire devices such as heat detectors or
pull stations.
Note: You must provide a mechanical means of resetting four‑wire smoke
detectors or other latching devices on zone4. The panel does not drop power
to the keypad bus or AX‑Bus when a Sensor Reset is performed.
Use the supplied 311 1K Ohm End‑of‑Line (EOL) resistors on each zone. Refer to the
panel programming guide for programming instructions. See Table 1 and Figure 8 for
more information on wiring the zone terminals.
