XR500/XR100 User’s Guide 51Appendix A
Arming and Disarming Event Displays
This displays any system area arming or disarming events.
Keypad Display Description
ARM 5:10P 10/17
WAREHOUSE
The Warehouse was armed on
October 17 at 5:10 PM. Press
any Select key to display the area
number and user number, and
then any Select key to display the
user name.
Arming Event Types - There are two event types you may see:
ARM - User armed the system DIS - User disarmed the system
Zone Event Displays
This displays alarms, troubles, and other events that may occur on
your protection zones.
Keypad Display Description
ALR 10:23P 10/17
BASEMENT DOOR
An alarm occurred on October 17
at 10:23 PM. Press any Select key
to see the zone number and zone
type.
Zone Type - There are seven possible zone types you may see:
FIRE - Fire PANC - Panic BURG - Burglary
EMRG - Emergency SUPV - Supervisory
AUX1 - Auxiliary 1 AUX2 - Auxiliary 2
Event Types - There are seven event type you may see:
ALR - Alarm TBL - Trouble RST - Restore
FLT - Zone Fault SVC - Service smoke detector
LOW - Low battery MIS - Missing wireless transmitter
Note: LOW and MIS are for wireless systems only.
Supervisory Event Displays
This displays the date and time of an automatic test report.
Keypad Display Description
MSG 11:58P 10/ 17
AUTO RECALL
The test report was sent to the
central station at the date and
time shown.
User Code Change Event Displays
This displays any addition, deletion, or change to a user code.
Keypad Display Description
ADD 11:41A 10/17
U:19 BY U:12
User 19 added at 11:41 AM by
user 12. Select either user (US:)
number for the user name.
User Code Event Types - There are three event type you may see:
ADD - User added DEL - User deleted
CHG - User code or authority level changed.
Zone Bypass Event Displays
This displays zone bypass events.
Keypad Display Description
BYP 5:18P 10/17
EAST WINDOW
The east window zone was
bypassed. Press any Select key
for the zone number and user
number. Press again for the user
name.
Bypass Event Types - There are three event types:
BYP - Bypass RST - Restore FRC - Force Arm
Note: You may sometimes see the user as SWG. This is short for
Swinger Bypass which is an automatic function that allows the
system to automatically bypass a zone.
