52 XR500/XR100 User’s Guide Appendix A
System Monitor Event Displays
This displays any problems with the system AC power, battery, or
phone line(s), or any opening of a tampered panel box.
Keypad Display Description
TBL 11:41A 10/17
POWER
An AC failure occurred on October
17 at 11:41 AM.
System Monitor Event Types - There are two event types:
TBL - Trouble RST - Restore
SystemMonitorEventNames-Therearevesystemmonitors:
POWER - AC power to panel BATTERY - On panel
LINE 1 - Phone line number 1 LINE 2 - Phone line number 2
TAMPER - On panel box
Door Access Event Displays
This displays the keypad address where a Door Access occurred and
the user number of the person granted access.
Keypad Display Description
ACC 5:18P 10/17
3 USER:024
User 24 accessed door (keypad) #3
at 5:18 PM on October 17. Press
the rst Select key to display
the Door name where the access
occurred. Press the second Select
key to display the reason access
was denied. Press the third Select
key for the name of the device, or
the fourth Select key for the user
name.
About Door Access
Door Access is a feature available on certain keypads that contain
a built-in door releasing relay and proximity readers. When power
for an electric door strike or magnetic lock is connected to the
relay contacts, only users entering a valid user code can release
the lock and gain access to the area.
The Display Events feature logs the user number and name of the
person granted access, the date and time, and from which keypad
they entered their code.
