XR500/XR100 User’s Guide 55Appendix B
Bypass Zones Browser
BYPASS ZONES?
ZONE: - RST BYP
SELECT ZONE . . .
Access the User Menu.
Press COMMAND to
display BYPASS ZONES.
Press any SELECT key/area.
Press either of the two
left SELECT keys/areas.
SELECT AREA . . .
FRONT OFFICE
When the area where the
zone is located displays,
press any SELECT key/area.
This prompt allows you to
search for a zone by area.
Press the COMMAND key
to scroll through the list of areas.
Press the COMMAND
key to scroll through
the zone names list.
EAST DOOR
When the correct zone
name displays, press
any SELECT key/area.
ZONE:012 RST BYP
The display shows the zone
number. SELECT RST to
Reset the zone. SELECT
BYP to Bypass the zone.
ZONE: - RST BYP
The display returns to
the ZONE: prompt
allowing you to enter
another zone number.
CMD
CMD
Zone Monitor Browser
SELECT ZONE . .
.
Access the User Menu. Press
COMMAND until ZONE MONITOR?
displays. Press any SELECT key/area.
SELECT NBR .
FRONT OFFICE
When the area where the zone is
located displays, press any SELECT
key/area.
Press either of the two left
SELECT keys/areas.
Press the COMMAND key to scroll
through the zone names list.
EAST DOOR
When the correct
zone name displays,
press any SELECT
key/area.
ZONE:012 ADD RMV
The display shows
the zone number.
ZONE MONITOR?
ALL NBR
ZONE: - ADD
RMV
Selecting ADD places
the zone in monitor mode.
Selecting RMV
removes the zone
from monitor mode.
SELECT AREA . .
.
This prompt allows you to search for a
zone by area. Press the COMMAND key
to scroll through the list of areas.
CMD
CMD
