Appendix D
XR500/XR100 User’s Guide 61
Appendix D
DMP Wireless Description
If your system uses DMP Wireless devices and includes key fob(s),
refer to the following information. The DMP Wireless section
includes a brief discussion of key fob(s) and a drawing identifying
the key fob buttons. Refer to the System Setup section of this guide
to check the button programming list for key fob(s) connected to
your system.
For best operation, allow the LED to light and turn off before
pressing another button. The key fob may not complete sending
the signal for the button press if another button is pressed too
soon.
LED Status Operation
Depending on the programmed action of a key fob button, the
Status LED lights to acknowledge a button press or to indicate the
armed state of the system.
• When the button is programmed for Panic, Panic 2,
Emergency, Emergency 2, Output, or Sensor Reset, a 1/2
second Green light displays to acknowledge the button
press.
• WhenthebuttonisprogrammedforArm,Disarm,Toggle
arm/disarm, or Status, the system armed status is
received by the key fob and the LED lights once as shown
in the table below.
LED Color Duration Description
Red 2.0 Seconds All System On
Green 2.0 Seconds All System Off
Green/Red 2.0 Seconds
System On
(Some Areas Armed)
When a button programmed as Unused is pressed, the LED does not
operate.
