XR500/XR100 User’s Guide 53Appendix A
Schedule Change Event Displays
This displays Changes made to the system schedules.
Keypad Display Description
S1 9:41A 10/17
MON USER:024
S1 schedule for Monday was
changed by user 24 at 9:41 AM on
October 17.
ScheduleTypes-Therearevepossiblescheduletypes:
S1 S2 S3 S4 - Standard OUT - Output
DOOR - Door HOL - Holiday EXT - Extend
MON - This is the day of the week in which the schedule change
occurred.  The days display using three letters.  Press the rst
Select key to display the scheduled Opening time and once again
for the scheduled Closing time.
024 - User number of the person who made the change. Press the
third Select key under 024 to display the user name.
Wireless Jamming Event Displays
This displays wireless jamming events that have occurred.
Keypad Display Description
ALM 11:41A 10/17
WIRELESS
The DMP wireless receiver
detected jamming on October 17
at 11:41 AM.
Wireless Jamming Event Types - There are three event types:
TBL - Trouble (a jamming event occurred when the panel was
disarmed)
ALM - Alarm (a jamming event occurred when any area was
armed)
RST - Restore
Note: Trouble and Restore events display WIRELESS as the device.
Wireless Trouble Event Displays
This displays events when the wireless receiver was not
communicating with the panel.
Keypad Display Description
TBL 11:41A 10/17
WIRELESS
A DMP wireless device trouble
occurred on October 17 at 11:41
AM.
Wireless Trouble Event Types - There are two event types:
TBL - Trouble RST - Restore
Note: Trouble and Restore events display WIRELESS as the device.
