FIRE CONTROL PANEL FEATURES
Figure 1: Fire Control Panel Features
Keyswitch
POWER
TROUBLE
ALARM
COMMAND
1 2 3 4
5 6 7 8
9 0
ABC DEF GHI JKL
MNO PQR STU VWX
YZ
ENABLE
SILENCE
RESET
TEST
DRILL
Fire Command Center
Select KeysLCD DisplayStatus LEDs
Function Keys
Data Entry Keys
Back Arrow Key
COMMAND Key
