Digital Monitoring Products, Inc. | XR Fire Control Panel User Guide 27
System Test is used to test the battery, alarm bell or siren, and communi cation to a
central station. The System Test function begins automatically as soon as you select it.
Using the System Test Function
1. Access the User Menu. Press COMMAND until SYSTEM TEST? displays.
2. The keypad displays SYSTEMPANICS. Press the Select Key below SYSTEM.
3. The System Test begins automatically and the keypad displays the following
messages in this order:
a. BELL SOUNDING during a two second bell test
b. KEYPAD SOUNDING all keypads assigned to the same area sound
their alarm tone for two (2) seconds during the keypad sounder test
c. BATTERY-OKAY or BATTERY-TRBL to indicate the battery condition
d. *TRANSMIT TEST and ATTEMPT NO: 1 during the transmit test
e. TRANSMIT OKAY or TRANSMIT FAILED to show the results of the
transmit test
f. TEST END to indicate the System Test is complete.
g. You can press the Back Arrow key to end the transmit test.
* The transmit test does not occur on local systems.
System Test
