XR200/XR2400F Programming Guide Digital Monitoring Products
9
3 - COMMUNICATION
3.3 2ND Phone Line
Allows you to use a second communication line to send reports to the SCS-1
Receiver should the first phone line fail. The default 2nd Phone Line for the
XR200 is NONE. The default 2nd Phone Line for the XR2400F is DD.
If 2ND LINE is DD or CELL (and you are not using a 462N Network Interface Card),
you will need to install a DMP 893 or 893A Dual Phone Line Module to connect both
the main and secondary phone lines to the panel.
Both DD and MPX type systems can be backed up with a dialer or cellular line.
Multiplex lines cannot be used as a secondary line.
NONE - A second line is not used.
DD - Dialer communication to a DMP SCS-1 Receiver. When using M2E or CID as
the main Communication Type, choose DD to communicate to an M2E or CID
receiver on the 2ND LINE.
CELL - Cellular dialer communication with Cell-Miser™ restrictions. When Cell-
Miser is selected, the following call restrictions apply to the panel.
1. Only zone alarms, Ambush, Line 1 Trouble, Abort, Recall Test, and Delayed
Events are sent over the cellular system. Delayed Events are only sent if the
cellular call was made for one of the other allowed reports.
2. Line 1 Trouble is sent only once during each armed period.
3. The dialing sequence uses the first phone number on line 1 only and the
second phone number on line 2 only. This allows the panel to use the cellu-
lar phone number for cellular calls only without needing prefixes or area
codes for land line dialing.
If 2ND LINE = DD If 2ND LINE = CELL
Panel dials the 1st ph # twice on Line 1 Panel dials the 1st ph # twice on Line 1
Panel dials the 1st ph # twice on Line 2 Panel dials the 2nd ph # twice on Line 2
Panel dials the 2nd ph # twice on Line 1 Panel dials the 1st ph # twice on Line 1
Panel dials the 2nd ph # twice on Line 2 Panel dials the 2nd ph # twice on Line 2
Panel dials the 1st ph # twice on Line 1 Panel dials the 1st ph # twice on Line 1
D2 - Select D2 to allow supervision of a second telephone line connected to a
Model 893 or 893A Dual Phone Line Module. D2 is only displayed if HST is the main
Communication type.
M2E - Select M2E to allow 2nd line communication using the Modem IIe format
when HST is the main communication type. M2E is only displayed if HST is the
main communication type.
HST (HOST) - DMP Asynchronous communication to a DMP SCS-1 Receiver or Host
automation system. If HST is selected as the Communication Type, HST will not
be displayed as an option in 2ND LINE. If HST is selected for 2ND LINE, all zone
alarms and restorals are duplicated on the asynchronous channel in addition to the
main communication method.
When HST is used as the main or 2ND LINE communication method, the account
number must not begin with a number that matches a line number being used for
multiplex service on the same SCS-1 Receiver. This allows the Redisplay Non-
Restored status list to work properly in receivers with SCS1/805 or higher
firmware.
2ND LINE: NONE
NONE DD CELL HST
NONE DD CELL D2
NONE DD CELL HST
M2E
