DMP Electronics XR200 User Manual

XR200/XR2400F Programming Guide Digital Monitoring Products
47
17.12 Zone Type Specifications
Description of the programmable zone options
Below is a description of the various zone options shown on the table above. For additional information, read
through the Zone Information section of this manual.
Zone Type Defaults - These are complete spellings of the abbreviations used for the zone types.
Type - These are the abbreviations used for the zone types.
Area - For a ALL/PERIM or HOME/SLEEP/AWAY system, this is either Interior, Bedroom, or Perimeter. For an
AREA system, 1 to 8.
Wireless - This zone is connected to a wireless transmitter. For use with the FA400 Remote Wireless Receiver.
Message - A = alarm report, T = trouble report, L = local with no report, - (dash) = no report, S = Sensor Reset and
alarm silence.
Output - These are the ten on-board and 200 off-board relay outputs.
Action - This selects the action of the output: S = steady, P = pulse, M = momentary, and F = follow
Swinger - The zone can be automatically shunted after a programmed number of trips.
Prewarn - This selects the keypad address that sounds the entry prewarn for this zone.
Entry Delay - This is the entry delay timer selected as the default for this zone.
Retard Delay - Provides a programmed retard time before an alarm is initiated from a shorted zone.
Presignal - Provides a keypad tone for zones in retard delay.
Fast Response - Provides a 167ms zone response instead of the normal 500ms response.
Cross Zone - Provides cross zoning with any of the 242 available zones.
Priority - Requires this zone to be in a normal condition before the area can be armed.
Style - These are the abbreviations you will see on the keypad for arming zone style:
TGL = Toggle, ARM = Arm only, DIS = Disarm only, STEP = Wireless arming, MNT = Maintain
XR200 ZONE INFORMATION Type Area Fire
Disarmed Disarmed Armed Armed
Open Short Open Short
INT Bell
Assign area and disarm condition
for NT, DY, EX, A1, A2, and AR onl
y
NT
BDRM Output
DY EX
Assign Prewarn and Entry Delay
for EX only
FI PN
PERIM
Wireless
Message Output Action Message Output Action Message Output Action Message Output Action Swinger Prewarn Entry Delay Retard Delay Presignal Fast Response Cross Zone Priority Style
EM SV
Partition Number
YA SA SA SA SN1 1N1NNNTGL
A1 A2 or T P T P T P T P or to to or to or or or ARM
Assign Retard and Presignal
for FI, SV, A1, A2, and FV only FV AR 1
1 to 10NL ML ML ML MY84Y8YYYDIS
to 1 - 8 100 to - F - F - F - STEP
Abbr.
4 299 S* S* MNT
NIGHT NT 00A0A0Y NNN
DAY DY T0 T0 A0 A0 Y NNN
EXIT EX 00A0A0Y1-81NNN
FIRE FI T0 A0 N N+NNN
PANIC PN T0 A0 N NNN
EMERGENCY EM T0 A0 N NNN
SUPERVISORY SV T0 A0 N N+NNN
AUXILIARY 1 A1 T0 A0 T0 A0 N N+NNN
AUXILIARY 2 A2 T0 A0 T0 A0 N N+NNN
FIRE VERIFY FV T0 A0 N N N
ARMING AR TGL
– = This function is not enabled for this zone type.
= These zone functions are not available for this zone type.
+ = Retard must be YES before Presignal can be selected.
* = When SV zone is connected to 303 Silence/Reset Switch
17 - APPENDIX
