Digital Monitoring Products XT30/XT50 Installation Guide
16
COMPLIANCE
Listed Compliance Specications
20.1 Introduction
The programming and installation specications contained in this section must be completed when installing
the XT30/XT50 in accordance with any of the ANSI/UL burglary standards. Additional specications may be
required by a particular standard.
20.2 Bypass Reports
The bypass reports must be programmed as YES for all listed burglary applications.
20.3 Current Draw
The total current draw from a combination of auxiliary, smoke, and bell output terminals must not exceed
1.6 Amps.
20.4 Battery Standby
Use battery Models 365 (12VDC 9Ah) or 366 (12VDC 18Ah) with the XT30/XT50 panel when installed in the
340, 341, 349, or 349A enclosures. The Model 364 (12VDC 1.3Ah) battery is for use with the XT30/XT50 panel
when using the 341 enclosure with the optional 341B Battery Bracket. The Model 364 battery is rated for 4
hours of standby time.
20.5 Auxiliary and Bell Current
For listed applications, the maximum auxiliary current is 400mA, and the maximum bell current is 500mA.
20.6 Cross Zoning
Each zone must have the capability of protecting the common area individually.
20.7 App Key
The Remote Option App Key has not been evaluated for use in listed applications.
Household Burglar-Alarm System Units
ANSI/UL 1023
21.1 Bell Cuto
The bell cuto time cannot be less than four minutes.
21.2 Entry Delay
The maximum entry delay used must not be more than 45 seconds.
21.3 Exit Delay
The maximum exit delay used must not be more than 60 seconds.
21.4 Wireless External Contact
When used, the External Contact of 1101, 1102 or 1106 must be programmed Normally Closed.
21.5 Wireless Supervision Time
The Zone Information Supervision Time cannot be set to 0 (zero).
21.6 Wireless Audible Annunciation
The Wireless Audible option must be selected as DAY for residential applications.
21.7 Panel location
Mount panel inside protected area.
21.8 Test Frequency
The Test Frequency option must be programmed to send a report at least once every 30 days.
Digital Burglar Alarm Communicator System Units
ANSI/UL 1635
22.1 Entry Delay
The maximum entry delay used must not be more than 60 seconds.
22.2 Exit Delay
The maximum exit delay used must not be more than 60 seconds.
22.3 Test Frequency
The Test Frequency option must be programmed to send a report once every 24 hours.
22.4 Automatic Bell Test
This option must be programmed as YES.
