DMP Electronics XT30 - Table of Contents

XT30/XT50 Installation Guide Digital Monitoring Products
i
TABLE OF CONTENTS
Panel Specications
1.1 Power Supply ..................................................................................................... 1
1.2 Communication ................................................................................................... 1
1.3 Panel Zones ........................................................................................................ 1
1.4 Keypads/Expansion ............................................................................................. 1
1.5 Number of Zones ................................................................................................ 1
1.6 Outputs .............................................................................................................. 1
1.7 EnclosureSpecications ...................................................................................... 1
Introduction
2.1 SystemCongurations ......................................................................................... 2
2.2 Caution Notes ..................................................................................................... 2
2.3 Compliance Instructions ...................................................................................... 2
System Components
3.1 WiringDiagram ................................................................................................... 2
3.2 LightningProtection ............................................................................................ 2
3.3 AccessoryDevices ............................................................................................... 3
3.4 XT30/XT50WiringDiagram ................................................................................. 4
Installation
4.1 MountingtheEnclosure ....................................................................................... 5
4.2 MountingKeypads .............................................................................................. 6
4.3 InstallationSpecications .................................................................................... 6
Primary Power Supply
5.1 AC terminals 1 and 2 ........................................................................................... 6
5.2 Transformer Types .............................................................................................. 6
5.3 PowerLED ......................................................................................................... 6
Secondary Power Supply
6.1 Battery Terminals 3 and 4 .................................................................................... 7
6.2 EarthGround ...................................................................................................... 7
6.3 Replacement Period ............................................................................................ 7
6.4 Discharge/Recharge ............................................................................................ 7
6.5 BatterySupervision ............................................................................................. 7
6.6 XT30/XT50 Power Requirements .......................................................................... 7
6.7 XT30/XT50 Standby Battery Calculations .............................................................. 8
Bell Output
7.1 Terminals 5 and 6 ............................................................................................... 9
Keypad Data Bus
8.1 Description ......................................................................................................... 9
8.2 Terminal7-RED................................................................................................. 9
8.3 Terminal 8 - YELLOW .......................................................................................... 9
8.4 Terminal9-GREEN ............................................................................................ 9
8.5 Terminal 10 - BLACK ........................................................................................... 9
8.6 KeypadBusLEDs ................................................................................................ 9
8.7 Programming(PROG)Connection ........................................................................ 9
8.8 KeypadAddressing .............................................................................................. 9
8.9 OvercurrentOVCLED .........................................................................................10
Smoke and Glassbreak Detector Output
9.1 Terminal 11 .......................................................................................................10
Burglary Zones
10.1 Description ........................................................................................................10
10.2 Operational Parameters ......................................................................................10
10.3 Zone Response Time ..........................................................................................11
10.4 KeyswitchArmingZone ......................................................................................11
