XT30/XT50 Installation Guide Digital Monitoring Products
1
PANEL SPECIFICATIONS
Panel Specications
1.1 Power Supply
Transformer Input: Plug-in — 16.5VAC 40 VA, Model 321
Wire-in — 16.5VAC 40 VA, Model 320
Standby Battery: 12VDC, 1.0 Amps Max. charging current
Models 364, 365, 366, 368, or 369
Replace every 3 to 5 years
Auxiliary Output: 12VDC at 500mA
12VDC at 325mA when used with two Model 364 batteries in the Model 341
Enclosure
Bell Output: 12VDC at 1.5 Amps
Smoke Detector Output: 12VDC at 100mA
All circuits inherent power limited
Note: Please see the Listed Compliance Specications section for certicated application requirements.
1.2 Communication
Built-in SDLC Digital Dialer communication to DMP Model SCS-1R Receivers
Built-in network communication to DMP Model SCS-1R or SCS-VR Receivers
Modular cellular communication to DMP Model SCS-1R or SCS-VR Receivers
Modular Wi-Fi network alarm signal communication to DMP Model SCS-1R or SCS-VR Central Station
Receivers.
Built-in CID (Contact ID) dialer communication to DMP Model SCS-1R Receivers
1.3 Panel Zones
Nine 1k Ohm EOL burglary zones: zones 1 to 9
One 3.3k Ohm EOL Class B powered re zone with reset capability: zone 10
1.4 Keypads/Expansion
Connect up to eight supervised alphanumeric keypads.
Connect up to four alphanumeric 9000 Series wireless keypads.
Eight keypads total per panel.
Connect additional unsupervised keypads.
• Graphic Touchscreen, Thinline™, Aqualite™, Clear Touch™, and Icon keypads
In addition, the following zone expanders can be added:
• One, four, eight and 16-zone expansion modules
• Single-zone PIR and glassbreak detectors
1.5 Number of Zones
• Onboard zones 1-10
• Eight keypad bus addresses with zones 11-14, 21-24, 31-34, 41-44, 51-54, 61-64, 71-74, and 81-84
• Zone numbers 31 to 34 and 41 to 44 can support 1100 Series Key Fobs or DMP wireless output modules
• XT50 has 20 additional onboard wireless zones numbered 80-99
1.6 Outputs
The XT30/XT50 panels provide four open collector outputs rated for 50mA each. A Model 300 Output Harness
is required. The open collector outputs provide the ground connection for a positive voltage source.
1.7 Enclosure Specications
The XT30/XT50 panel ships standard in a 340 enclosure with EOL resistors, battery leads, user’s guide, and
programming sheet.
Enclosure Model Size Color Construction (Cold Rolled Steel)
340 12.5” W x 9.5” H x 2.75” D Gray (G) 20-Gauge
349 12.5” W x 11.5” H x 3.5” D Gray (G) 20-Gauge
349A 13.25” W x 11.65” H x 3.6” D Gray (G) 18-Gauge with 16-Gauge door
341 13” W x 6.55” H x 3.5” D Gray (G) 20-Gauge
