Doble TDR900 User Guide
72A-2612-01 Rev. A 09/06
8
2.8 Analog/Event Cable Option
The Analog and Event Cables allow for measurements using external sensors. Event
channels are also called Auxiliary channels. This is where an analog sensor, such as a clip
on CT would be connected.
Figure 8. TDR900 Analog/Event Connections
