6.6.2 Breaker
The “Breaker” tab, as shown in Figure 23, gives information about the breaker file just
opened. In a new test plan, the field entries will be blank.
Figure 23. Breaker Tab - Nameplate Sub-Tab
There are four sub-tabs:
• Nameplate
• Timing Limits
• Travel Limits
• Velocity Limits
Each of these allows entry of data for a specific breaker type for a library plan or for a
specific breaker (Serial Number or Spec ID required) for a breaker plan.
6.6.2.1. Nameplate
The Nameplate tab is shown in Figure 23. Edit field contents by clicking in that field.
6.6.2.2. Timing Limits
The default settings for the Timing Limits are given in the “Timing Limits” tab, as shown
in Figure 24.
