COOLING SYSTEM SPECIAL TOOLS
COOLING
DESCRIPTION N·m Ft. In.
Lbs. Lbs.
Automatic Belt Tensioner to
Mounting
Bracket—Bolts(5.2L/5.9L) 67 50 —
Automatic Belt Tensioner to
Block—Bolts
(4.7L) 41 30 —
Automatic Belt Tensioner
Pulley—Bolt
61 45 —
Block Heater—Bolt 2 — 17
Generator/Compressor
Mounting
Bracket—Bolts
# 1 and 2 54 40 —
# 3 40 30 —
Fan Shroud Mounting—Bolts 6 — 50
Fan Blade to Fan Drive—
Bolts
23 17 —
Idler Pulley—Bolt 54 40 —
Radiator to Support—Bolts 23 — 200
Thermostat Housing—Bolts 23 — 200
Transmission Auxiliary Oil
Cooler—Bolts
10 — 90
Upper Radiator Closure
Panel—Bolts
10 — 90
Water Pump—Bolts 40 30 —
Pliers Constant Pressure Hose Clamp—6094
Cooling System Pressure Tester—7700A
3/8” Disconnect Tool—6935
7 - 44 COOLING SYSTEM DN
SPECIFICATIONS (Continued)
