Fig. 13 Securing Timing Chain Tensioners Using Timing Chain Wedge
1 – LEFT CYLINDER HEAD
2 – RIGHT CYLINDER HEAD
3 – SPECIAL TOOL 8350 WEDGE
4 – SPECIAL TOOL 8350 WEDGE
Fig. 12 Camshaft Sprocket V8 Marks
1 – LEFT CYLINDER HEAD
2 – RIGHT CYLINDER HEAD
DN 4.7L ENGINE 9 - 21
SERVICE PROCEDURES (Continued)
