TEST ACTION APPLICABILITY
8 Turn the ignition off.
Disconnect the Instrument Cluster C1 harness connector.
Measure the resistance between ground and the Instrument Cluster Ground circuit.
Is the resistance below 5.0 ohms?
All
Yes → Replace and configure the Instrument Cluster in accordance with
the Service Information.
Perform BODY VERIFICATION TEST - VER 1.
No → Repair the Instrument Cluster Ground circuit for an open.
Perform BODY VERIFICATION TEST - VER 1.
443
INSTRUMENT CLUSTER
*ALL GAUGES INOPERATIVE — Continued
