Domino Ax150i User Manual

OPERATION
EPT019297 Issue 1 November 2016 4-53
Export a Label(s)
Home > Setup > File Manager > USB
To export a label from the printer to a USB flash drive:
(1) Insert a USB flash drive into the USB port on the TouchPanel.
(2) Wait until the USB icon on the information bar turns green.
(3) Select Home > Setup > File Manager.
(4) Navigate to the required label store on the printer.
(5) Select the Edit icon next to the label to be exported.
(6) Select either Cut or Copy.
(7) Navigate to the USB folder.
(8) Select Paste.
(9) Remove the USB flash drive from the TouchPanel.
End of procedure.

Domino Ax150i Specifications

General

Print Technology	Continuous Inkjet (CIJ)
Printhead	i-Pulse printhead
User Interface	Touchscreen
Connectivity	Ethernet, USB
Operating Temperature	5°C to 45°C
Ink Type	MEK-free options available
Maximum number of lines	5
