Domino Ax150i User Manual

SYSTEM DESCRIPTION
2-12 EPT019297 Issue 1 November 2016
i-Pulse Duo (Ax350i/Ax550i only)
Standard Finish: Chassis: Stainless steel
Wire box: Acetal
Holster: Black anodised aluminium
Dimensions: Width: 57mm (2.24")
Depth (Max): 53mm (2.01")
Height: 255mm (10")
Weight: 2.8kg including 3m conduit (6.17lbs)
Printer type, conduit
length and nozzle size
options:
Printer Type Conduit Length Nozzle Size
Ax350i/Ax550i 3m (10ft) 60 or 75 micron
Ax350i/Ax550i 6m (20ft) 60 or 75 micron
Recommended distance
from print surface:
75 micron nozzle: 12mm (0.47")
60 micron nozzle: 8mm (0.31")
Working height relative to
cabinet base:
3m conduit: ±1m
6m conduit: ±3m

Domino Ax150i Specifications

General

Print Technology	Continuous Inkjet (CIJ)
Printhead	i-Pulse printhead
User Interface	Touchscreen
Connectivity	Ethernet, USB
Operating Temperature	5°C to 45°C
Ink Type	MEK-free options available
Maximum number of lines	5
