Domino Ax150i User Manual

INSTALLATION
EPT019297 Issue 1 November 2016 3-39
Ink Jet Throw Distance Setup
WARNING: Protective equipment such as gloves and glasses must be worn when
working on or near the printer. Physical contact with ink or make-up
can cause skin or eye damage.
The throw distance setting is used to define the distance between the bottom of the print head
and the print surface.
Tools required: Metric ruler.
To setup the throw distance:
(1) Measure the distance between the bottom of the print head and the print surface.
(2) If it is possible, position the print head to the recommended distance away from the print
surface as described in the table below.
Note: The nozzle diameter of the printer can be found on the TouchPanel by selecting Home
> Setup > System information and viewing the Nozzle diameter (μm) value.
(3) On the TouchPanel, select Home > Setup > Production line setup > Print trigger.
(4) Scroll down to the Throw distance (mm) setting and select it.
(5) Enter the actual distance between the bottom of the print head and the print surface.
(3) Select the green Tick icon.
End of Procedure.
Ink Jet Velocity Setup
The Jet velocity (mm/s) setting is used to define the velocity of the ink drops between the nozzle
and the print surface. However, it is recommended to leave this value at the default setting.
To setup the ink jet velocity:
(1) On the TouchPanel, select Home > Setup > Production line setup > Print trigger.
(2) Scroll down to the Jet velocity (mm/s) setting and select it.
(3) Enter a jet velocity value (Range: 15000 - 30000).
(4) Select the green Tick icon.
End of Procedure.
Nozzle
Diameter
Recommended Throw
Distance
75 micron 12mm
60 micron 8mm

Domino Ax150i Specifications

General

Print Technology	Continuous Inkjet (CIJ)
Printhead	i-Pulse printhead
User Interface	Touchscreen
Connectivity	Ethernet, USB
Operating Temperature	5°C to 45°C
Ink Type	MEK-free options available
Maximum number of lines	5
