SYSTEM DESCRIPTION
EPT019297 Issue 1 November 2016 2-13
User Interface
TouchPanel Type 3 (Ax350i/Ax550i Only)
TouchPanel Type 4 (Ax350i/Ax550i Only)
Standard Finish: Cast aluminium (rear), nylon plastic (front)
Mounting: Via angled bracket to cabinet top.
VESA 75 standard mounting.
Display: 10.4 inch SVGA full colour touch screen
Dimensions: Width: 307mm (12.1")
Height: 232mm (9.1")
Depth: 75mm (3")
Weight: 2.5Kg (5.5lb)
IP Rating: IP65
Temperature: 5 - 45°C
Humidity: 10 - 90% non-condensing
Power Supply: 24Vdc, 15W, 625mA over non standard DVI
Connectivity: Non standard DVI cable to rear of printer
Data Transfer: 2 x USB Type A
Standard Finish: Nylon plastic
Mounting: Via angled bracket to cabinet top.
VESA 75 standard mounting.
Display: 7 inch WVGA full colour touch screen
Dimensions: Width: 245mm (9.6")
Height: 160mm (6.3")
Depth: 50mm (2")
Weight: 0.75Kg (1.65lbs)
IP Rating: IP55
Temperature: 5 - 45°C
Humidity: 10 - 90% non-condensing
Power Supply: 24Vdc, 12W, 500mA over non standard DVI
Connectivity: Non standard DVI cable to rear of printer
Data Transfer: 2 x USB Type A
