Domino Ax150i User Manual

OPERATION
4-62 EPT019297 Issue 1 November 2016
GLOBAL PRINT SETTINGS
Note: Engineers certified by Domino can refer to the Engineers Reference Guide for further
details of the functionality described in this section.
Position / Orientation
Home > Setup > Global print settings > Position / orientation
Notes: (1) Everyday adjustments to print height, print delay, invert and reverse should be made
on the Print Optimisation screen, see page 4-9.
(2) These are global settings which will affect all label designs when printed. The Invert
and Reverse settings can also be configured and saved with individual label designs,
see page 4-22.
Select/set the following:
Setting Name Explanation
Charge scaling(%) Set the nominal print height by adjusting the charge on the ink
drops.
EHT(%) Set the nominal print height by adjusting the charge on the EHT
plates in the print head.
Print delay (mm) Set the distance between a product sensor detecting a product
and the label being printed.
Print height (%) Adjust the print height percentage.
Invert Invert the label.
Reverse Reverse the label.

Domino Ax150i Specifications

General

Print Technology	Continuous Inkjet (CIJ)
Printhead	i-Pulse printhead
User Interface	Touchscreen
Connectivity	Ethernet, USB
Operating Temperature	5°C to 45°C
Ink Type	MEK-free options available
Maximum number of lines	5
