INSTALLATION
3-18 EPT019297 Issue 1 November 2016
TouchPanel to Networked Printers
One TouchPanel can control multiple printers in the same network if required. However, the
TouchPanel can only connect to 1 printer at a time.
Create a List of Favourite Printers
It is recommended to create a list of favourite printers in the TouchPanel if there is more than 1
printer on the same network which the TouchPanel can connect to.
To create a favourite list of the printers:
(1) Select the Lock icon on the bottom right corner of the TouchPanel screen.
(2) Select Disconnect from printer.
(3) Select the Lock icon on the bottom right corner of the TouchPanel screen.
(4) Select Unlock UI settings.
(5) Enter the UI password (Default password: QS).
(6) Select the green Tick icon.
(7) Select OK.
(8) Select UI Settings.
(9) Select the Connection Method drop down setting and select Favourite.
(10) Select Add favourite...
(11) Enter the following information:
(12) Select the green Tick icon.
(13) The details of the printer will now appear on the screen. Select the printer to connect to it.
(14) Either select Add favourite... to add another printer, or select the Network icon in the bottom
left of the TouchPanel screen.
(15) Select a printer from the favourite list to connect to.
End of procedure.
Setting Name Explanation
Name Enter the name of the printer.
Type Select the type of printer which the TouchPanel is connecting to.
For an Ax-Series printer, select CIJ.
IP address Enter the IP address of the printer.
Host Enter the host name.
