Domino Ax150i User Manual

INSTALLATION
3-12 EPT019297 Issue 1 November 2016
TouchPanel Connectivity
The TouchPanel Type 3 and 4 are connected to the TouchPanel connector on the rear of the
Ax350i/Ax550i printer. The TouchPanel will then display the user interface relating to that printer
when the printer is turned on.
CAUTION: To reduce the risk of damaging cables or equipment, securely route the
TouchPanel cable away from moving equipment and other hazards.
TouchPanel
Connector
TouchPanel Connection

Domino Ax150i Specifications

General

Print Technology	Continuous Inkjet (CIJ)
Printhead	i-Pulse printhead
User Interface	Touchscreen
Connectivity	Ethernet, USB
Operating Temperature	5°C to 45°C
Ink Type	MEK-free options available
Maximum number of lines	5
