Domino Ax150i User Manual

SYSTEM DESCRIPTION
EPT019297 Issue 1 November 2016 2-15
Cabinet Status Lights
There are a number of status lights on the printer cabinet as illustrated below.
Cabinet Status Light Explanation
Printer Off, Power
Connected
The red light on the power button will illuminate to indicate that
the printer is connected to a power supply but the printer is not
turned on.
Start Up
The red light on the power button will illuminate, and the green
light on the power button will flash to indicate that the printer is
starting up.
Printer On / Shut Down
The green light on the power button will illuminate to indicate that
the printer is on.
The light will flash on and off to indicate that the printer is shutting
down.
Red Alert
The red alert light will illuminate to indicate a red alert. A red alert
occurs when the printer has a fault which causes printing to stop.
If a TouchPanel is connected to the printer, a description of the
alert will be displayed on the TouchPanel’s status tab.
Amber Alert
The amber alert light will illuminate to indicate an amber alert. An
amber alert occurs when the printer has a fault which requires
attention. If a TouchPanel is connected to the printer, a description
of the alert will be displayed on the TouchPanel’s status tab.
Make-up Level Alert
If the make-up level is ok, the light will be off.
The make-up light will illuminate to indicate when the make-up
level is low and the cartridge requires replacement.
The make-up light will flash on and off to indicate when the
make-up level is empty and the cartridge requires intimidate
replacement.

Domino Ax150i Specifications

General

Print Technology	Continuous Inkjet (CIJ)
Printhead	i-Pulse printhead
User Interface	Touchscreen
Connectivity	Ethernet, USB
Operating Temperature	5°C to 45°C
Ink Type	MEK-free options available
Maximum number of lines	5
