9.3.39. Cooling fan
¥
Install the cooling fan and flange, then
tighten the fixing boltd.
9.3.40. V- belt
¥
Install the V-belt on the crank pulley,
alternator pulley and fan drive pulley.
¥
Adjust the V-belt tension using the ten-
sion adjusting bolt.
9.3.41. Oil level gauge
¥
Assemble the oil level gauge and guide
tube on the oil pan.
9.4. Breaking-in
Refer to ÒBreaking-inÓ in chapter of ÒCommissioning and OperationÓ.
- 112 -
