9.1.7. Guide tube of oil level gauge
¥
Loosen the flange nut installed on the oil
pan to remove the guide tube.
9.1.8. Fuel filter
¥
Remove fuel hoses connected to the fuel
injection pump, take off the bracket fixing
bolts, then disassemble the fuel filter.
9.1.9. Breather
¥
Loosen the clamp screw to remove the
rubber hose.
9.1.10. Intercooler
¥
Tear down the various hoses and air
pipes from the inter cooler.
¥
Remove the intercooler fixing bolts and
tear it down.
- 62 -
