5.5. Fuel System
5.5.1. Fuel filter
¥
After every 200 hour of operation, drain
the water and sediment from the fuel-
water separator.
¥
Shut off the engine. Use your hand to
open the drain valve .
¥
Turn the valve counter clockwise approxi-
mately 2 ~ 3 turns until draining occurs.
Drain the filter sump of water until close
fuel is visible.
¥
Turn the valve clockwise to close the drain
valve. Do not over tighten the valve, over-
tightening can damage the threads.
5.5.2. Replacement of fuel filter
¥
Clean the area around the fuel filter head
.
¥
Remove the fuel filter by turning it
counter-clockwise with filter wrench.
(Discard the used filter.)
¥
Remove the fuel filter thread adapter seal
ring .
¥
Use a clean lint free cloth to clean the gas-
ket surface of the fuel filter head .
¥
Install the new thread adapter seal ring
supplied with the new filter.
¥
Use clean oil to lubricate the filter seal , and fill the new filter with clean fuel.
¥
Install the filter on the filter head .
¥
Tighten the filter until the gasket contacts the filter head surface.
¥
Tighten the filter on additional one-half to three-fourths of a turn with the filter wrench, on as
specified by the filter manufacturer.
Notice : Mechanical over tightening of the filter can distort the thread or damage the filter
element seal.
