Remove the piston pin snap rings, take
off the piston pin, then disconnect the
connecting rod from the piston.
¥
Disassemble the piston rings using ring
pliers.
¥
Use care not to interchange the disas-
sembled parts and keep them in the
sequence of cylinder No.
9.1.35. Cylinder liner
¥
Disassemble the cylinder liner using a
liner puller.
9.1.36. Flywheel
¥
Position the engine so that the head
installing surface of the cylinder block
faces down.
¥
Unscrew the flywheel fixing bolts and fit
a dowel pin.
¥
Install flywheel disassembling bolts in
the bolt holes machined on the flywheel,
and disassemble the flywheel.
- 70 -
