9.1.3. Engine oil
¥
Take out the oil dipstick.
¥
Remove the oil drain valve of oil pan and
drain out the engine oil into a prepared
container.
9.1.4. Alternator belt
¥
Loosen the tension adjusting nut installed
on the alternator bracket, and take off the
alternator belt.
9.1.5. Cooling fan
¥
Remove the flange fixing bolts, then take
off the flange and cooling fan.
9.1.6. Alternator
¥
Remove the alternator fixing bolt and dis-
assemble the alternator.
¥
Remove the tension adjusting bolt and
bracket.
- 61 -
