9.1.37. Oil seal
¥
Take off the rear oil seal using an oil seal
disassembling jig.
¥
If only the inside guide ring is removed,
use a special tool to take off the outside
seal.
9.1.38. Flywheel housing
¥
Loosen the housing fixing bolts disas-
semble the flywheel housing.
9.1.39. Cam shaft and tappet
¥
Remove the cam shaft gear.
¥
Take off the cam shaft gear thrust washer.
¥
Take out the cam shaft using care not to
damage the cam shaft.
¥
Slide out the tappets by hand.
9.1.40. Crankshaft gear and oil pump idle gear
¥
Loosen the socket head bolts and take
out the oil pump idle gear.
¥
Use a puller to remove the crankshaft
gear.
- 71 -
EAMD043I
EAMD044I
