Model 7000XL:
The operational controls for the Model 7000XL consist of the ZERO, PRINT and
UNITS buttons. A 6 digit LED display is used to provide weight indications and operator
messages describing scale operation. Scale status such as motion (MOT), polarity
(NEG) and center of zero (ZERO) are displayed on annunciators located to the left of
the display area. Scale units are displayed on four annunciators located to the right of
the main display.
Model 7000:
The Model 7000 controls consist of a single ZERO button located under the main
display. A single status annunciator, "NEG, " is used to display negative polarity. This
LED is located in the lower left corner of the display area. Four LED's located at the
bottom of the display indicate the current weighing units. Motion is indicated when the
units LED's are off. The LED's are on when stable.
ZERO:
The ZERO push button is used to zero the scale prior to making a reading. The zero
button can function over the full range of the scale or it can be limited to a zero band
equal to 1.9 % of scale capacity for Legal for Trade applications.
To zero the scale, wait until the scale is stable and press the ZERO button. The scale
will zero immediately. Neither the 7000XL or the 7000 will "zero" if the scale is in motion
or if it is outside of the 1.9% Legal for Trade zero band (when activated). Refer to
Section 4 of this manual for more details.
The 7000XL and the 7000 are equipped with an optional "Zero on Demand" feature
which holds "zero" requests until motion stops and capacity limitations have been
corrected. These options are activated during the scale setup procedure. Refer to
Section 4 of this manual for more details.
UNITS :
(Standard on the 7000XL, optional on the 7000)
The UNITS button provides the operator with the ability of changing the scale units by
pressing a button. The units indicator will immediately display the new units. The next
display update will indicate the correct weight in the new units.
The UNITS button has several configuration parameters which can disable the UNITS
button or limit the display units available. Refer to Section 4 of this manual for more
details.
PRINT:
(Standard on the 7000XL, optional on the 7000)
The PRINT button allows the operator to print the current weight by pressing a button.
Like the ZERO button, the user waits until motion stops before pressing the PRINT
button. The current weight will then be transmitted to the printer.
The PRINT button has a "Print on Demand" feature which stores PRINT requests until
the scale is stable. Once stable, the scale will transmits the current weight to the
printer. Several automatic print options are also available to simplify printer operation.
Refer to Section 4 of this manual for more details.
9
