Section 7: Specifications and Interconnect Data
Specifications:
Model 7000XL
Model 7000
Resolution:
6000d in precision mode
(5000d for Legal for Trade)
Sensitivity:
0.5 µV min.
Load Cell Capacity:
0.5 mV/V to 3.5 mV/V
Power Supply:
115/230 Vac 50/60 Hz
Display:
6 digit LED. 0.56" high
Displayed units:
lb, kg, oz and g
Capacities:
5lb to 100,000 lb
Printer Interface:
Bi-directional RS-232
Calibration
Unit may be calibrated with 10%, 25%, 50% and
100% of capacity.
Controls:
Rugged Polycarbonate
touch panel with built in
ZERO, PRINT and
UNITS switches.
Water tight ZERO
switch.
Optional PRINT or
UNITS switch.
Construction:
Rugged stainless steel NEMA 4/4x construction.
Options:
Dual Print permits weight printing in current units
and Kilograms.
User configurable remote switch.
4-20mA analog output.
Interconnect Data:
PIN # TITLE
1 Chassis Ground
2 + Load Cell Signal
3 - Load Cell Signal
4 + Load Cell Excitation
5 - Load Cell Excitation
6 Chassis Ground
Table 1: TB1 Load Cell Connections
NOTE: When connecting the load cell, be sure to install the ESD
and EMI protection inductor. Refer to Fig. 3 for details.
36
